| Automatic Liquid Filling Capping And Labeling Machine |
| Model | TTP-020 |
| Filling Weight | 10-1000ml(customizable) |
| Bottle diameter | Φ30-Φ140mm(customizable) |
| Bottle height | 40mm-320mm （customizable） |
| Production speed | 10-55 Bottle/min |
| Measurement accuracy | ≤500ml，≤±1%；＞500ml，≤±0.5% (Varies due to the characteristics of the material) |
| Power | 4.5kw |
| Working Pressure | 0.6-0.8MPa |
| Control system | PLC |
| Filling head | four heads/ten heads,can be customized |
| Weight | 1200kg |
This type of machine is suitable for filling viscous, inviscid, and corrosive liquid. It's widely applied in plant oil, chemical liquid, and the daily chemical industry. It adopts linear type filling,electromechanical&instrucmental integration controlling.It's simple and rapid for changing the varieties with unique design and superior capability. Its appearance accords with the international machinery concept.
Germany SIEMENS PLC and touch screen control make it an intelligent protection function. Vacuum anti-dropping device ensures no leaking situation in production. Electronic adjusting for volume system, frequency control, and photoelectric detecting system(Germany TURCK brand) are applied in this machine.
